100% Customization per Drawing

Ball-Lock Punches

Quick-change ball-lock punches, button dies and retainers for progressive, compound and transfer dies — quarter-turn retention with zero axial play, H7/m6 self-centering shank fit, A2 / M2 / PS4 steel at HRC 58–62, Dayton and MISUMI interchangeable, 15–30 s per punch change.

Quarter-turn ball-lock retention — no setscrews, no wrenches, no alignment errors
15–30 seconds per punch change; die changeover time cut by 60%+
A2 / M2 / PS4 tool steel, vacuum heat treated to HRC 58–62
H7/m6 self-centering shank fit, retention resists stripping 10× vs setscrew
Dayton & MISUMI interchangeable; ISO 10071-1 shank sizes Ø6–32 mm
MOQ 1 piece — standard 3–7 days, urgent 24–72 h

Download CAD / Specs

Fast Response within 2 HoursSupport STEP, IGES, DWG, PDF Files

Technical Specifications

Ball-Lock Punches Technical Parameters & Material Specs

Standard Materials

A2 / M2 / PS4

Vacuum heat treated high-wear tool steel

Shank Diameter Range

Ø 6 – Ø 32 mm

Inch 1/4" – 1-1/4" per ISO 10071-1 & Dayton

Hardness Range

HRC 58 – 62

Critical sizes ground to ±0.002 mm

Retention System

Ball-lock teardrop groove

Quarter-turn lock, zero axial play

Parameter	Technical Details / Standard Values
Shank (Head) Diameter	Ø 6 – Ø 32 mm standard; inch 1/4" – 1-1/4" per ISO 10071-1, Dayton & MISUMI interchange
Point Diameter & Shape	Round, square, rectangular & oblong points; point-larger-than-shank supported
Overall Length (L)	Up to 150 mm standard; custom lengths machined per drawing
Tool Steel Grades	A2 (D2 / SKD11), M2 (SKH51), PS4 powder steel, optional carbide tips
Hardness Range	HRC 58 – 62 after vacuum heat treatment
Retention Method	Teardrop groove + spring-loaded ball; H7/m6 self-centering shank-to-bore fit; quarter-turn lock/unlock

Need a non-standard size or special alloy core pin? We specialize in 100% custom machining according to your 2D/3D CAD drawings.

APPLICATION & INDUSTRY SOLUTIONS

Ball-Lock Quick-Change Systems for High-Speed Stamping Applications

🚗 Automotive

Automotive Progressive Dies

High-volume progressive dies running 500+ SPM on AHSS and stainless. Ball-lock cuts punch changeover from 45 min to under 10 min per die; ejector punches prevent slug pulling at speed.

🔌 Electronics

Electrical Connector Stamping

Terminal pins, socket contacts and housings in copper alloy and phosphor bronze. DLC-coated punches prevent galling where positioning tolerances run ±0.02 mm.

⚙️ Job Shop

Job Shop & Contract Stamping

5–10 die changeovers per week across multiple presses. Standardized retainers enable interchangeable punch inventory; punch blanks allow same-day custom fabrication.

🏭 Heavy Duty

Heavy Blanking & Compound Dies

Reinforced punch bodies for 3–6 mm stock and interrupted cuts, paired with A2 button dies for matched die clearances and extended edge life.

Key Mold Performance Challenges We Resolve:

Heat Fatigue & Thermal Cracking

Vacuum-quenched H13/SKD61 steel prevents thermal erosion in aluminum & zinc die casting.

High Wear & Galling Resistance

Advanced PVD coatings (TiAlN / DLC) extend pin service life by 3x–5x in abrasive glass-filled resins.

Mold Pin Bending & Flash Issues

Strict coaxiality (≤0.003 mm) and rigid alloy cores eliminate flash and core deflection during high-pressure injection.

CUSTOM MACHINING CAPABILITIES

Tailored Ball-Lock Punches Machining & Special Processing Limits

📏 Dimensional Limits

Micro & Complex Dimensions

Outer Diameter (OD): Min Ø 0.2 mm to Max Ø 50.0 mm
Pin Length: Up to 600 mm (ultra-long ball-lock punches supported)
Special Shapes: Stepped, tapered, flat D-cut, square head & eccentric pin tip

⚙️ Special Processes

Cooling & Deep Hole EDM

Cooling Channels: Internal water cooling holes & spiral baffle channels
Air Venting: Porous / vented ball-lock punches structures for gas release
Micro-EDM: Complex cavity contours, thread inserts and micro-grooves

🛡️ Surface Treatments

Advanced PVD Coatings

TiN / TiAlN: High-heat resistance for die casting molds
DLC (Diamond-Like Carbon): Ultra-low friction for dry / cleanroom molding
Nitriding Treatment: HV 900–1100 surface hardness for extended mold life

Support 100% Customization According to Your Drawings

Send us your CAD files for a free DFM (Design for Manufacturability) analysis and instant quotation.

.STEP.IGES.DWG.DXF.PDF

QUALITY ASSURANCE & INSPECTION

Rigorous Precision Inspection & Quality Control Standards

🔬 Inspection Hardware

High-Precision Testing Equipment

ZEISS CMM for complex 3D contours
Nikon optical projector & tool presetters (0.001 mm resolution)
Vickers hardness testers & surface roughness gauge

🎯 Quality Standards

Zero-Defect Quality Assurance

100% critical dimension inspection before packaging & shipment
Concentricity & runout verification under optical magnifiers
Surface micro-scratch & polish quality double-check

📜 Material Compliance

Full Material & Heat Treatment Traceability

Spectrometer material composition analysis report provided
Original Mill Test Certificate (MTC) & heat treatment logs
RoHS & REACH environmental compliance statements

Download Sample Quality Control & Inspection Reports

Review our standard CMM inspection sheet, Material Composition Certificate, and RoHS report templates.

MANUFACTURING PROCESS & LEAD TIME

Precision Machining Workflow & Reliable Delivery Timelines

Turning / Soft CNC

Precision rough turning & blank shaping

Heat Treatment

Vacuum quenching (HRC 48–62)

Rough Grinding

Centerless & OD precision grinding

Finish Grinding / EDM

Jig grinding & micro-EDM features

Surface Coating

PVD (TiN/DLC) or polishing (Ra 0.1)

100% CMM QC

Dimension check & safe packaging

📦 Standard Delivery

3–5 Working Days

For standard dimensions, off-the-shelf standard blanks, and standard SKD61/H13 materials.

🛠️ Custom Manufacturing

7–10 Working Days

For tailored CAD drawings, complex cooling channels, special coatings, or tight ±0.002 mm tolerances.

⚡ Fast-Track Option

24–72 Hours Express

Emergency mold repair green channel available for urgent downtime orders (upon CAD review).

MANUFACTURING CAPABILITY & DETAIL GALLERY

Precision Craftsmanship & Advanced Factory Hardware

Mirror Finish & Micro Polish

Ra 0.1 µm surface roughness, zero micro-burr or tool marks on pin tip.

Precision Chamfering & R-Angle

Smooth transition radii and precise lead-in chamfers per CAD specs.

PVD Coating & Nitriding Layers

Uniform TiAlN / DLC coating film thickness with high surface adhesion.

Complex Head & Tip Geometries

Precision stepped, D-cut flat, and eccentrically shaped pin profiles.

High-End Machining & Tooling Hardware:

⚡ Wire EDM

Seibu & Sodick Slow-Feed Wire Cut

Corner radius accuracy down to R0.02 mm
Surface roughness Ra 0.2 µm after wire cutting
Suitable for micro-slots, keyways, and complex pin contours

⚙️ Precision Grinding

Mitsui & WASINO Precision Grinders

Centerless & jig grinding for tight OD/length limits
Diameter tolerance controlled within ±0.001–±0.002 mm
Coaxiality & roundness ≤ 0.002 mm guaranteed

🛠️ CNC & EDM

Mikron High-Speed CNC & Sodick EDM

CNC high-speed turning & milling for blank preparation
Micro-cavity EDM for cooling channels and venting slots
Automated tool changers for high-volume consistency

ORDERING PROCESS & FREQUENTLY ASKED QUESTIONS

How to Order Custom Ball-Lock Punches & Frequently Asked Questions

📁 Step 1

Submit CAD & Specs

Send 2D/3D drawings (STEP, DWG, PDF) with quantity, material, and tolerance requirements.

⏱️ Step 2

24H DFM & Quotation

Our engineering team conducts DFM analysis and provides a competitive quote within 24 hours.

⚙️ Step 3

Precision Manufacturing

CNC turning, vacuum heat treatment, jig grinding, and surface coating per your specifications.

✈️ Step 4

100% QC & Express Shipping

100% CMM dimensional verification, anti-rust packaging, and global air express delivery.

What is your Minimum Order Quantity (MOQ) for custom ball-lock punches?

We support 1-piece prototyping! Whether you need a single replacement ball-lock punches or bulk batch production of 10,000+ pieces, we accommodate all order volumes.

How do you guarantee material authenticity and heat treatment quality?

Every batch comes with original Mill Test Certificates (MTC) and spectral material analysis reports. Vacuum heat treatment logs (HRC hardness testing) are provided upon request.

What packaging and anti-rust protection do you apply for international shipping?

All finished ball-lock punches undergo ultrasonic cleaning, immersion in heavy-duty anti-rust oil, individual vacuum plastic sealing, and padded shockproof box packaging.

Can you machine non-standard custom shapes or internal cooling channels?

Yes! We specialize in complex ball-lock punches including stepped profiles, D-cuts, square heads, micro-EDM cavities, and internal/spiral water cooling channels per CAD specs.

Ready to Upgrade Your Mold Component Precision?

Send us your drawing today to receive a free DFM review and detailed quotation within 24 hours.

🔒 100% Confidential | NDA Protected | Instant DFM Assessment
